1000V Voltage Rating Servo Motor Connector with 18-24 AWG Wire Gauge and Metal/Plastic Material for Industrial Automation

Product Description:

Servo Motor Connectors play a crucial role in the reliable and efficient operation of various motor control systems, including DC Servo Motor Drive, Brushless Servo Motor, and AC Servo Motor Driver applications. These connectors are specifically designed to ensure secure electrical connections between the motor and the control unit, facilitating smooth communication and power transmission essential for precise motor control. With a focus on durability, performance, and versatility, servo motor connectors come with a range of attributes tailored to meet the demanding needs of modern servo motor systems.

One of the key features of servo motor connectors is their contact plating, which significantly affects conductivity and resistance to corrosion. Typically, these connectors utilize silver-plated contacts or gold-plated pins. Silver plating is prized for its excellent electrical conductivity and relatively low cost, making it a popular choice for many applications. Gold-plated pins, on the other hand, offer superior resistance to oxidation and wear, ensuring long-term reliability, especially in environments where connectors are frequently mated and unmated. This combination of silver contact plating and gold-plated pins ensures optimal performance in demanding servo motor environments, such as those involving DC Servo Motor Drives or Brushless Servo Motors.

Current rating is another critical specification for servo motor connectors. These connectors are available with current ratings ranging from 1A up to 10A and beyond, depending on the specific application requirements. For instance, smaller servo motors used in precision instruments might only require connectors rated for 1A, while larger industrial servo motors or AC Servo Motor Drivers may demand connectors capable of handling 10A or more. This wide range of current ratings ensures that the connectors can accommodate different power levels without compromising safety or performance.

The wire gauge compatibility of servo motor connectors is designed to support a variety of conductor sizes, typically ranging from 18 to 24 AWG, and in some cases, supporting even larger gauges such as 3 to 12 AWG in diameter. This flexibility is essential because servo motor systems often use different wire gauges depending on the power requirements and signal transmission needs. For example, finer wires like 24 AWG may be used for signal connections, while thicker wires such as 18 AWG or larger are employed for power lines. The ability to accommodate a broad range of wire gauges makes these connectors versatile and suitable for integration into numerous servo motor configurations.

Material composition plays a vital role in the durability and functionality of servo motor connectors. Most connectors are constructed using a combination of metal and plastic materials. The metal components, usually made from high-quality alloys, provide mechanical strength and ensure excellent electrical conductivity. The plastic parts, typically engineered thermoplastics, serve as insulators and structural elements that protect the contacts from environmental factors such as dust, moisture, and mechanical stress. This combination of metal and plastic materials results in connectors that are robust, lightweight, and capable of withstanding harsh industrial conditions commonly encountered in applications involving DC Servo Motor Drives and AC Servo Motor Drivers.

Insulation resistance is another important attribute, especially for connectors with multiple pins such as 6-pin or 7-pin configurations. High insulation resistance ensures that there is minimal leakage current between adjacent pins, which is critical to maintaining signal integrity and preventing short circuits. The 6-pin and 7-pin servo motor connectors are typically designed with excellent insulation resistance properties, making them suitable for complex servo motor systems that require multiple signal and power lines within a single connector assembly. This feature is particularly important in Brushless Servo Motor applications, where precise control signals must be transmitted without interference.

In summary, servo motor connectors are essential components for the seamless operation of DC Servo Motor Drive, Brushless Servo Motor, and AC Servo Motor Driver systems. Their silver-plated or gold-plated contacts ensure excellent conductivity and corrosion resistance, while current ratings from 1A to 10A or more accommodate varying power demands. The wide wire gauge compatibility from 18-24 AWG and beyond provides flexibility for different wiring requirements. Constructed from durable metal and plastic materials, these connectors offer mechanical strength and protection against environmental factors. Additionally, high insulation resistance in 6-pin and 7-pin versions guarantees reliable signal transmission and safety. Together, these attributes make servo motor connectors indispensable for achieving high-performance, reliable, and efficient motor control in a wide range of industrial and commercial applications.

Features:

• Product Name: Servo Motor Connectors
• Operating Temperature Range: -40℃ to +105℃
• Material Composition: Metal and Plastic
• Model Name: 6FX2003
• Compatible Wire Gauge: 18-24 AWG or More, AWG 3-12 Diameter
• Connector Type: Servo Motor
• Designed for use with Hydraulic Brake Motors
• Ideal for High Torque DC Servo Motor applications
• Ensures reliable connectivity in Hydraulic Brake Motors systems

Technical Parameters:

Applications:

The NO MARK 6FX2003 Servo Motor Connectors are designed to meet the rigorous demands of modern industrial automation systems. Manufactured in China and certified by CE and ISO9001 standards, these connectors ensure reliable and efficient performance in various servo motor applications. With a minimum order quantity of 100 pieces and a supply ability of 1000 pcs/day, they are readily available to support large-scale production needs. The packaging comes securely in carton boxes, and delivery time ranges from 1 to 3 working days, making them ideal for businesses requiring quick turnaround. Payment options include T/T and PayPal, providing flexibility and convenience for customers worldwide.

These connectors are compatible with a range of servo motor types, including DC Servo Motor Drive systems, High Torque DC Servo Motors, and Brushless Servo Motors. Their robust design supports multiple gender configurations such as 8pin, 4PIN, 6PIN, 12PIN, and 17PIN, catering to diverse wiring requirements. The connectors accommodate wire gauges from 18-24 AWG or even larger, with diameters ranging from AWG 3 to 12, ensuring versatility and adaptability in complex wiring environments.

Engineered to operate within a wide temperature range of -40℃ to +105℃, the 6FX2003 connectors are suitable for harsh industrial environments where temperature fluctuations are common. This makes them an excellent choice for applications in factory automation, robotics, CNC machinery, and other automated systems that rely on precise motor control and reliable electrical connections.

In industrial automation scenarios, these connectors facilitate seamless integration between servo motor drives and control units, enhancing system efficiency and reducing downtime. They are essential in applications where high precision and durability are critical, such as in assembly lines, packaging machines, and automated guided vehicles (AGVs). The ability to support high torque DC servo motors and brushless servo motors further broadens their applicability, making them indispensable components in advanced motion control systems.

Overall, the NO MARK 6FX2003 Servo Motor Connectors offer exceptional reliability, versatility, and ease of installation, making them a preferred choice for engineers and system integrators working with DC servo motor drives, high torque DC servo motors, and brushless servo motors in demanding industrial automation settings.

Customization:

Our Servo Motor Connectors, model number 6FX2003, are designed to meet the highest standards in industrial automation. Manufactured in China under strict quality control with CE and ISO9001 certification, these connectors ensure reliable performance for applications including Hydraulic Brake Motors, AC Servo Drive systems, and High Torque DC Servo Motor setups.

We offer product customization services tailored to your specific needs, supporting wire gauges from 18-24 AWG or larger, with diameters ranging from AWG 3 to 12. The connectors are rated for voltages up to 1000V and can handle current ratings from 1A to 10A and beyond, making them suitable for a wide range of servo motor applications.

Our connectors operate reliably in harsh environments with an operating temperature range of -40℃ to +105℃. Packaged securely in carton boxes, we maintain a supply ability of 1000 pieces per day, with a minimum order quantity of 100 units. Delivery time is swift, typically within 1-3 working days.

Payment terms are flexible, accepting T/T and PayPal for your convenience. Choose our Servo Motor Connectors for dependable connectivity in your Hydraulic Brake Motors, AC Servo Drive, and High Torque DC Servo Motor projects, backed by quality and prompt service.
